Equipment

Maximum Gear Dimensions

TYPE OF GEAR	PITCH DIAMETER	DIAMETRAL PITCH	FACE WIDTH	UNGROUND TOOTH	GROUND TOOTH
Spiral Bevel Gear	16 inches	3 to 40 DP	3.5 inches	AGMA Class 11	AGMA Class 14
Zerol Bevel Gear	12 inches	3 to 40 DP	2.5 inches	AGMA Class 11	AGMA Class 13

*Combined Maximum’s Must Be Reviewed

X Travel (Width)	Y Travel (Depth)	Z Travel (Height)
41.3’’	20.8’’	76.4’’

*Combined Maximum’s Must Be Reviewed

Diameter (Max)	Length (Max)
36.2’’	75.6’’

*Combined Maximum’s Must Be Reviewed

Diameter (Max)	Length (Max)
36.2’’	75.6’’
